W1209 Digital Thermostat
W1209 Digital Thermostat

W1209 Digital thermostat temperature

KSh700.00 KSh500.00

19 in stock

W1209 Digital Thermostat
W1209 Digital thermostat temperature

KSh700.00 KSh500.00

SKU: 10573 Categories: Sensors, Shields & Modules, Temperature, humidity & air
CATEGORIES
  • Computer Accessories
  • Development Platforms
    • Arduino Starter Kit
    • Starter Kit
    • STM Boards
    • Arduino Development Boards
    • Raspberry Pi
  • Aeronautics & Robotics
    • Flight controllers
    • Other robotics &aeronautics accesories
    • Robot chasis
  • Batteries & Chargers
  • Electronic components
    • Buzzer/Holders/Dc jack
    • Capacitors/Resistors/Leds
    • Connectors/Header pins/Stackable pins/Jumper wires
    • Crystal/Diodes/Transistors
    • Drill bits/Glue sticks
    • Inductors
    • Potentiometer
    • Switch
    • Currrent
  • Gyro & Accelerometer
  • Integrated Circuits
    • Opamps
    • Mosfet drivers
    • 74 Series
    • ADC/DAC
    • Attiny
    • CMOS 4000 series
    • Comparators
    • Darlington Array Drivers
    • voltage regulators ics
  • LCDS & Displays
  • Microcontrollers
    • Attiny
    • ATMEL Chips
    • PIC Series
  • Programmers
    • Stm Programmers
    • Other Programmers
    • Pic Programmers
  • Prototyping & tools
    • Prototyping
    • Tools
  • Relays, Motors, Motor drivers, Pumps & Valves
    • Motor driver module
    • Motor drivers
    • Motors
    • Pumps
    • Relays
    • Valves
  • Sensors
    • Currrent
    • Gyro & Accelerometer
    • Light, Laser & Sound
    • Proximity
    • RF sensors/Bluetooth & IR
    • RFID/NFC/WIFI/FM
    • Biometrics
    • Gas/Liquid
    • Temperature, humidity & air
    • Tracking
  • Shields & Modules
  • Wireless devices
    • RF sensors/Bluetooth & IR
    • RFID/NFC/WIFI/FM
    • Gps, Gsm & Gprs Devices
  • Uncategorized
blank
Description

W1209 Digital thermostat to Turn any application ON/OFF based on temperature reading

Description

-50-110°C W1209 Digital thermostat Temperature Control Switch 12V sensor Module

  • 12V Digital Heating Cooling Thermostat relay -50-110 °c Temperature Controller
  • Temperature control range: -50~110 °c
  • Resolution: 0.1 °c under -9.9-99.9°c (or 1°c in other temperature range)
  • Measure accuracy: 0.1 °c
  • Backlash setting: 0.1 -15°c
  • Refresh rate: 0.5 S
  • Input Power: DC 12V
  • Output: One way 10A relay
  • Temperature protection: 0-110 °c
  • Working temperature: -10~60 °c
  • Working humidity 20%~85%
  • Static current: ≤ 35MA
  • Attract current: ≤ 60MA
  • Sensor Cable:Yes, NTC 10K 0.5% thermistor
  • Size: 48*40mm
  •  how to use instruction W1209 Digital thermostat

  • Use:Connect the power and the load, the controller can work,now it displays the measuredtemperature.
  • Press the SET button, the display flickers,please press ‘+ – ‘keys to set the temperature you want,then press the ‘SET’key to confirm and return,at this time the controller will automatically performs the relay on or off.please make sure the connection is correct.
  • Indicator: when it is Off,the relay is open, when it is continuously on, the relay is closed.
  • Digital tube: when it shows ‘LL’, the sensor is open. when it shows ‘HH’, the temperature is out of the measuring range, the relay will be shut down. when it shows’—‘, it is now high temperature protecting.
  • Parameter Setting Method: Long press SET 5 seconds to enter the main menu settings, press the ‘+ – ‘keys to switch P0 … P8. long press SET or 10 seconds no key activity it will confirm and return.
Settings Chart
  • Long press the “SET” button to activate the menu.
  • (SET THE VALUES AS MENTIONED IN BRACKET)
    Code Description Range Default Value
    P0 Heat C/H (C)
    P1 Backlash Set 0.1-15  (2)
    P2 Upper Limit 110 (110)
    P3 Lower Limit -39 (-39)
    P4 Correction -7.0 ~ (0)
    P5 Delay Start Time 0-10 mins  (0)
    P6 High-Temperature Alarm 0-110  (OFF)
    Long pressing “+/-” will reset all values to their default
APPLICATION :
  1. To measure and display temperature
  2. To Turn any application ON/OFF based on temperature reading. (Both AC and DC)
  3. Example Project:- A.Fire alarm system . B. Auto cut off Electric Water HeaterFeatures :
  4. Power Consumption
    1. Static Current: <=35mA
    2. Current: <=65mA
  5. Environmental Requirements
    1. Temperature: -10 ~ 60 C
    2. Humidity: 20-85%
