LM35DZ Analog Temperature Sensor Probe

K-TECHNICS
Out of stock
KSh500.00

Secure checkout

Friendly support

Hassle-free returns

Take your environmental tracking into tough environments with the Waterproof LM35DZ Analog Temperature Sensor Probe. Encapsulated in a high-quality stainless steel tube and sealed with internal thermal sealant, this probe protects the precision LM35DZ chip from moisture, rust, and dust. It is the perfect plug-and-play solution for tracking liquid temperatures, outdoor weather, or aquaponics systems.

Unlike basic thermistors that require complex code and beta-coefficient math, this probe delivers a linear analog voltage output directly proportional to the Celsius scale ($+10\text{mV}/^\circ\text{C}$). Reading the temperature is as easy as plugging the probe into your microcontroller’s analog-to-digital converter (ADC) and reading the voltage!

Key Features & Benefits

  • Waterproof & Rust-Resistant: Heavy-duty stainless steel housing ($6\text{mm} \times 50\text{mm}$) ensures the internal sensor stays completely dry and functional in liquids.

  • Direct Celsius Readings: Calibrated directly in Centigrade out of the box—no complex math or lookup tables needed.

  • Pre-Wired for Convenience: Comes with a generous 1-meter ($100\text{cm}$) insulated lead cable with color-coded wires for instant hookup.

  • Ultra-Low Self-Heating: Draws less than $60\,\mu\text{A}$, preventing the sensor from heating itself up and skewing your liquid or air readings.

  • Universal Microcontroller Support: Interfaces seamlessly with Arduino, Raspberry Pi, ESP32, and PIC platforms.

Technical Specifications

Feature Specification
Sensor IC LM35DZ
Probe Casing High-Quality Stainless Steel
Probe Dimensions 6mm Diameter times 50mm Length
Cable Length Approx. 1m
Temperature Range 0-100 degrees celsius
Accuracy ±0.5°C at 25°C
Operating Voltage 4-20V DC (5V recommended)
Output Type Analog Voltage (10mV/°C)

Wiring & Pinout Guide

The probe comes with 3 color-coded lead wires for clean integration:

  • 🔴 Red Wire: VCC (Power Supply Input, $4\text{V} - 20\text{V}$)

  • 🟡 Yellow (or White) Wire: VOUT (Analog Signal Output)

  • ⚫ Black Wire: GND (Ground)

Common Applications

  • Liquid Temperature Sensing: Perfect for aquariums, water tanks, pools, and hydroponic nutrient reservoirs.

  • Outdoor Weather Stations: Weatherproof design handles rain, snow, and high humidity with ease.

  • Brewing & Food Science: Monitor mash tuns, fermentation setups, or refrigeration temperatures.

  • Industrial & Pipeline Monitoring: Attach directly to pipes or machinery for reliable thermal logs.
