Key Features & Functional Advantages

  • Massive Performance Boost: The 2.4GHz Cortex-A76 CPU offers a 2-3x speed increase over the previous generation, effortlessly handling complex computing tasks, emulation, and containerized services.

  • PCIe 2.0 Interface: Features a dedicated single-lane PCIe port, opening the door for high-bandwidth peripherals like NVMe solid-state drives for incredibly fast boot and read/write speeds.

  • Upgraded RP1 I/O Controller: The in-house southbridge chip more than doubles aggregate USB bandwidth and replaces older ports with two interchangeable 4-lane MIPI transceivers for dual cameras or displays.

  • Built-in Power Button: A highly requested, soft-touch onboard power switch allows you to safely shut down and power up the system without constantly unplugging the USB-C cable.

  • Integrated Real-Time Clock (RTC): Keeps accurate time even when disconnected from the internet and power grid, powered by a dedicated battery header.

Technical Specifications

  • Device Type: Single-Board Computer (SBC)

  • Processor (SoC): Broadcom BCM2712, Quad-core Cortex-A76 (ARM v8) 64-bit @ 2.4GHz

  • Memory Options: 2GB, 4GB, 8GB, 16GB LPDDR4X-4267 SDRAM

  • Networking: Gigabit Ethernet (PoE+ compatible), 2.4 GHz & 5.0 GHz 802.11ac Wi-Fi, Bluetooth 5.0 / BLE

  • USB Ports: 2 × USB 3.0 ports (simultaneous 5Gbps), 2 × USB 2.0 ports

  • Video Output: 2 × micro-HDMI ports (up to 4Kp60 with HDR support)

  • Peripheral Expansion: 1 × PCIe 2.0 x1 interface (requires separate M.2 HAT)

  • GPIO: Standard 40-pin header (backwards compatible)

  • Power Input: 5V/5A DC via USB-C (Power Delivery enabled)
